OVERVIEW

The THUNDERBOLT rifle offers uncompromising performance and accuracy. Featuring our unique polymer coated rifle stock, designed to excel in the harshest operating environments experienced by the modern day soldier. It is both ergonomically pleasing with the unparalleled build quality our customers have come to expect. Ideal for Law enforcement, Military and Government Agency application.

ADJUSTABLE BUTT PLATE
The THUNDERBOLT stock features a folding butt as standard for easy bore sighting, cleaning, maintenance and transit. The butt incorporates an adjustable cheek rest, length adjustment, butt pad height adjustment and a quick deployment mono pod with thumbwheel fine adjustment.

Rifle shown features the optional adjustable cheek rest.

Full length picatinny rail

The Picatinny scope rail is available with a parallel or angled option to suit the weapon and/or customer requirements. All THUNDERBOLT rifles are equipped with a 600 mm long Picatinny top rail to accommodate additional thermal and night vision equipment. The forend tube comes equipped with both side and lower Picatinny rails as standard for additional accessory attachment.

match grade barrel

SCD barrels are produced to a very high quality match grade specification, fluted for improved heat dissipation and rifle balance. SCD barrels are coated black and threaded for fitting muzzle brake and/or sound moderator.

muzzle brake as standard

Our highly efficient muzzle brake is a standard fitment to all of our tactical rifles and greatly reduces recoil and increases control of rifle movement during the firing process.

FULLY ADJUSTABLE BI-POD AS STANDARD

The SCD bipod is fully height adjustable and fits directly to the forend. The bipod features a swivel action which rotates around the centreline of the bore.

This feature minimises shot deviation due to torque reaction. The bipod features a quick release mechanism and needs no tools for removal or fitting.

corrosion / wear resistant coating

Low friction and wear resistant coatings reduce the need for lubrication. The weapons are ideally suited for the extremes of heat, cold, damp and dry dusty conditions found in current operational environments.

2-point safety

The rifle safety lever is incorporated in the trigger mechanism for ease of use.

2-stage trigger drop test compliant

A high-quality trigger is vital to enable shooter and rifle to perform together. All SCD triggers have two (2) stage operation, first and second pull, factory set to 1.5 kg. pull weight. The release is both crisp and predictable. Maintenance requirement is minimal. The complete trigger unit can be readily removed for cleaning.

FOLDING STOCK
QUICK RELEASE ADJUSTABLE MONOPOD
OPTIONAL ADJUSTABLE CHEEK
HIGH TENSILE STEEL RECEIVER

Specifications



THUNDERBOLT SC-76

THUNDERBOLT SC-86

7.62 x 51 NATO

CALIBRE

8.6 x 70 (0.338 Lapua Magnum NATO)
Dependent upon ammunition, shooter skills and visibility.
Short Barrel – 600 m
Long Barrel – 1,000 m

ENGAGEMENT RANGE

Dependent upon ammunition, shooter skills and visibility.
Short Barrel – 1,200 m
Long Barrel – 1,800 m
Using match grade ammunition, group size as defined by SCD is measured fro shot centre with four shot group at 100 metres.
1/2 MOA  (0.15 Mil)

ACCURACY

Using match grade ammunition, group size as defined by SCD is measured fro shot centre with four shot group at 100 metres.
1/2 MOA  (0.15 Mil)
10 Rounds

MAGAZINE

10 Rounds
Short Barrel – 20″ (50.1 cm)
Long Barrel – 26″ (66 cm)

BARREL LENGTH

Short Barrel – 20″ (51 cm)
Long Barrel – 27″ (69 cm)
1:11 (1:27.9 cm)

BARREL TWIST

1:10 (1:24.5 cm)
Short Barrel – 41″ (104 cm)
Long Barrel – 47″ (119 cm)

OVERALL LENGTH

Short Barrel – 43″ (109 cm)
Long Barrel – 50″ (127 cm)
Short Barrel – 32″ (81 cm)
Long Barrel – 38″ (96 cm)

FOLDED LENGTH

Short Barrel – 33″ (84 cm)
Long Barrel – 40″ (102 cm)
Weight will vary according to accessories and specification.
15.7 lb (7.14 kg)

OPERATIONAL WEIGHT

Weight will vary according to accessories and specification.
17 lb (7.7 kg)
Black and Dark Earth

STOCK COLOURS

Black and Dark Earth
Standard (add 0.46 lb (0.21 kg))

MUZZLE BRAKE

Standard (add 0.46 lb (0.21 kg))
Standard (add 1 lb (0.45 kg))

BIPOD

Standard (add 1 lb (0.45 kg))
Standard

FIELD TOOL KIT

Standard
Standard

FIELD CLEANING KIT

Standard



OPTIONS

Tactical Day Scope and Rings
Night Vision and LADS
Infra-Red and TI Sights
Waterproof Case
Drag Bag
Sound Suppressor
Sling
Training
